What is Q-Box?
Why Tae-Chang thinks Q-Box is necessary.

Earthquake, tsunami, distress, marine / marine accidents, mountain, air …
Isn’t there a product that can tell where I am in the event of a disaster and have the necessary functions to rescue me?



Prior to the Sewol disaster, we already decided that a solution is necessary to prepare for personal disasters for the lives and safety of the people in the domestic and foreign disaster safety market

Also, we planned, developed, patented, and completed the development of the Q-Box (Resident Location Signal Machine), a disaster prevention solution that can send location signals under any circumstances, such as earthquake, sea, seabed, mountains, and unconscious.



Q-Box is designed to prepare for the worst.
It may not be used for a lifetime, but it includes many features that can save lives in a single use.
Q-Box has been developed to minimize the human, physical and social costs involved in saving people’s lives and rescuing activities.

FUNCTION OF Q-BOX

Sonar Transmission(SONAR)

Send a sonar transmission to a dedicated receiver and position it

Underwater distance
– About 1.2~1.5km

Wireless Transmission (GPS+LoRa, Optional)

Receive position coordinates from GPS satellites and transmit position coordinates via LoRa module

Even if there is no communication network, it can be located by dedicated receiver

Wireless transmission distance
– About 1.6km (about 16km when repeater installed)

Hydraulic/Impact sensor

Automatically operate SONAR at set water pressure

– example : Automatic transmission of SONAR when more than 1m or 3 seconds

Automatically transmit radio transmission by shock or collision

Operating time/Battery

72 hours of continuous operation

waiting time : 6 months

3.7V / 650mAh x 2pcs

The world's first personal Sonar Transmitter

Size: 65 x 85 x 18(mm)

Weight : 130g

Operational grade/Temperature

Estimating Direction

IP grade : IP68

-10 ~ +40℃

LED Light

0.5W x 1piece

In an emergent situation,
Q-Box will report your location.

Sonar Transmission(SONAR)

Send a sonar transmission to a dedicated receiver and position it

Underwater distance
– About 1.2~1.5km

Wireless Transmission (GPS+LoRa, Optional)

Receive position coordinates from GPS satellites and transmit position coordinates via LoRa module

Even if there is no communication network, it can be located by dedicated receiver

Wireless transmission distance
– About 1.6km (about 16km when repeater installed)

Hydraulic/Impact sensor

Automatically operate SONAR at set water pressure

– example : Automatic transmission of SONAR when more than 1m or 3 seconds

Automatically transmit radio transmission by shock or collision

Operating time/Battery

72 hours of continuous operation

waiting time : 6 months

3.7V / 650mAh x 2pcs

The world's first personal Sonar Transmitter

Size: 65 x 85 x 18(mm)

Weight : 130g

Operational grade/Temperature

Estimating Direction

IP grade : IP68

-10 ~ +40℃

LED Light

0.5W x 1piece
